Dyness
BF100 100 kWh
An outdoor commercial battery cabinet intended to work with an appropriately selected external inverter.
Technical specifications
| Parameter | Value |
|---|---|
| Nominal battery energy | 100 kWh |
| Battery chemistry | LFP |
| Operating voltage | 324.8–403.2 V DC |
| Rated battery current | 140 A |
| Depth of discharge | 95% |
| Cabinet protection | IP55 |
| Dimensions W × D × H | 725 × 1200 × 2260 mm |
| Weight | 1200 ± 100 kg |
Applications and use cases
- DC storage for a commercial hybrid PCS project.
- A cabinet option for a site needing approximately 100 kWh nominal storage.
Equipment scope / supply scope
- BF100-C100 battery cabinet with battery management and air cooling.
- The datasheet diagram shows the hybrid PCS as a separate system component.
Configuration
- Select an inverter/PCS using the current model-level compatibility documentation.
- PV MPPT, grid switchgear, metering and backup operation are defined by the project.
Installation considerations
- Plan lifting, floor loading and service access for the cabinet.
- Allow heat rejection and account for derating above 45 °C.
