Solis
S6-GC3P60K05-NV-ND
Commercial PV inverter with independent MPPT channels for flexible roof-array design.
Manufacturer series image; appearance may vary with model and configuration.
Technical specifications
| Parameter | Value |
|---|---|
| Rated AC power | 60 kW |
| MPPT / maximum strings | 5 / 10 |
| Maximum DC voltage | 1100 V |
| MPPT voltage range | 180–1000 V |
| Maximum efficiency — NV variant | 98.6% |
| Protection rating | IP66 |
| Dimensions / weight | 508 × 612 × 288 mm / 38.6 kg |
Applications and use cases
- Medium commercial rooftop PV.
- Distributed plants with several roof orientations.
Equipment scope / supply scope
- Integrated DC switch and two standard RS485 interfaces.
Configuration
- PV string design, AC protection and monitoring configuration.
- Wi-Fi, 4G and DRM options.
- Integrated AFCI 2.0 and PID recovery are optional.
- Manufacturer-described equipment and accessories; the quotation confirms the supplied configuration.
